Supporting service
CMM Programming
Request a quote for program development or revision.

Request a quotation
A program that measures the print, not just runs
Program development starts from the drawing or model, with GD&T interpreted into a datum structure and alignment strategy before a single point is taken. Fixture and feature strategy follow the part, not the machine's default routine.
Platforms in use across the region's Tier 1 suppliers include PC-DMIS, Calypso, MODUS, CAMIO, PolyWorks and Quindos.

What's covered
Programming support spans new part introduction through legacy program revision and reporting output.
- 01
Datum and alignment
Datum structure is built from the print's reference frame, not an arbitrary machine coordinate system.
- 02
Probe and stylus selection
Stylus configuration is chosen and qualified for access, deflection and feature size before programming begins.
- 03
Scanning vs. discrete point
Scanning mode is specified where form data is required; discrete points where it is not.
- 04
PPAP and first-article output
Report format is built to match the supplier's PPAP or first-article submission requirement.
Development sequence
- 01
Review print
GD&T callouts, datum structure and critical features are identified from the drawing or model.
- 02
Plan strategy
Fixturing, probe configuration and measurement sequence are laid out before programming.
- 03
Build and test
The program is run against a known-good or first-off part and checked against expected results.
- 04
Deliver and document
Finished program, stylus file and reporting template are handed over with the part.

Why Louisville CMM Calibration and Repair
- 01
Print-driven datum structure
Datum structure is built from the drawing's reference frame, not a default machine alignment.
- 02
Platform-matched
Programs are built in the software the shop already runs, not converted after the fact.
- 03
Stamping and forging experience
Programs account for the datum schemes typical of structural stampings and forged driveline parts.
Coverage across Kentucky and the Greater Midwest
On-site scheduling is confirmed by metro and travel distance at the time of quote; ship-in service is available outside the stated radius.
Discuss CMM Programming Requirements
Send the print, model and platform for a programming quote.
